HeartSave PAD (biphasic) with Lithium Battery

HeartSave PAD (biphasic) with Lithium Battery

PRIMEDIC HeartSave PAD defibrillator is easy to use with quick and safe operation.

It turns on automatically when the cover is opened.

The device performs an automatic ECG analysis within 12 seconds and determines when defibrillation is necessary. Then one button's push is enough to cause the salvage electric pulse to eliminate ventricular fibrillation. In addition, seconds can be valuable to saving life.

Performs automatic defibrillation "Current Controlled Defibrillation" at the touch of a button, has smart software for easy operation, automatically selects the energy of the electric pulse without needing adjustment.

It has a memory card, capable of storing up to 24 hours, for data and voice recording.

Small size and weight for easy movement.

It has an automatic external defibrillation function (AED) also provides a step-by-step guidance through clear voice prompts available in a variety of languages, also ECG, heart rate.

Technical Specifications:

Defibrillation:

Semi-automatic mode

Wave: biphasic, current controlled pulse

Energy: 50-360J

Charging time: < 12 sec @ 360J

Operating modes: asynchronous

Paediatric mode

ECG:

Patient's impedance range: 23-200 Ohm

VF:VT Detection:

VF/VT Detection

Analysis time 7-12 sec

Asystole threshold: <0.2mV

Artefact - Pacemaker detection

Electrodes:

Non polarized electrodes, cable length 2 m

Data backup:

Removable memory

Voice recording

Power supply:

Lithium battery 3 years life or 140 discharges at 360J
Status display

Defibrillator and battery status visualization
