Βipolar Surtron Touch HP 400 Watt,High frequency electrosurgical unit

Surtron Touch 200 Monopolar/Bipolar

Surtron touch has taken electrosurgery to new levels of performance, reliability and safety.

It’s an high frequency electrosurgical equipment which is suitable for precision monopolar and bipolar surgery and micro-surgery without tissue alterations. Surtron touch can supply HF operative powers either for programmable time as short as hundreds of a second.

Through its performances allows pure CUT, cut-coagulation BLEND, incision with reduced production of eschar ENHANCED, superficial coagulation FORCED COAG, deep coagulation in absence of necrosis SOFT COAG, bipolar CUT and COAG. The digital reading of the delivered power and the overseeing through microcontroller of the operational functions, assure the absolute reliability of the conditions of work. It allows a highly professional surgery thanks to the user-friendly and safety solutions normally used. The connection of neutral electrode is constantly monitored. Safety control of patient contact using split neutral electrode. The possibility to control by the handle the output functions as well as the delivery of output power, allows to implement the surgical operation without turning away the surgeon attention from the surgical field.

UNDERWATER CUTTING AND COAGULATION

FEATURES
Max power PURE CUT: 200 W – 300 Ω
Max power BLEND CUT: 150 W – 300 Ω
Max power ENHANCED CUT: 150 W – 300 Ω
Max power BIPOLAR TUR: 200 W – 50 Ω
Max power BIPOLAR PURE: 120 W – 50 Ω
Max power FORCED COAG: 150 W – 200 Ω
Max power SOFT COAG: 100 W – 200 Ω
Max power FULGURATION COAG: 100 W – 1000 Ω
Potenza max BIPOLAR COAG: 120 W – 50 Ω
Max power BIPOLAR SEALING: 200 W – 50 Ω
Working frequency: 360 kHz
RF power pulse emission time: 10ms-30sec
RF power pulse interval: 1-30
Patient circuit F
Selectable input voltage 90-240 Vac
Mains Frequency 50-60 Hz
Electrical input power 750 VA
Size WxHxD 370x145x300 mm
Weight 5.8kg

 Standard Accessories

Reusable handle with switches

Holter for handle and electrodes

Assorted electrodes (x10)

Blade electrode 7cm (x3)

Needle electrode 7cm (x3)

Ball electrode 6cm (x3)

Cable for neutral electrode

Steel neutral electrode

Disposable split neutral electrode (x2)

Waterproof foot switch

Power supply cable 5mt
